نام محصول:
دمنده هوا
نام انگلیسی:
Air blower OMEGA
برند:
KAESER Kompressoren
مشخصات:
Our single-block blowers provide maximum flexibility. The OMEGA series blowers with their three-lobe rotors minimise pulsation and include a wide range of rotary lobe blowers for stationary and mobile applications. They are manufactured in state-of-the-art, climate-controlled CNC production facilities and are rigorously tested at full load.
Highly versatile rotary lobe blowers – in stationary and mobile versions, suitable for both vacuum and pressure operation – for air and nitrogen conveying applications (OMEGA P and PN)
Blower with primary components made from chromium-nickel alloy for vacuum distillation / process water recycling (OMEGA B)
Vacuum blowers with pre-inlet cooling – suitable for alternating vacuum and pressure operation in tanker trucks and suction vehicles (OMEGA PV)
Rotary lobe vacuum pumps for fine vacuum applications (OMEGA WVC) in combination with a booster pump
Your advantages
Long service life:
Heavy-duty cylinder roller bearings completely absorb the continuously changing radial gas-forces that are exerted on the rotors. Service life of up to 100,000 hours is possible with the included bearings.
High flow rate = High-efficiency
Thanks to precision manufacturing we achieve minimal flank clearance, which results in reduced capacity losses through gap losses.
Field of application
Whether stationary or mobile, and in both vacuum and pressure operation – our rotary blowers ensure excellent performance for a wide range of applications. For example:
In water management (e.g. for aeration of sedimentation tanks)
Forced air generation (drying, cooling, separation…)
Combustion air supply
توضیحات:
Type
air
Technology
rotary
Number of stages
single-stage
Applications
for vacuum, heavy-duty, precision
Other characteristics
with pre-inlet cooling
Flow
Min.: 5 m³/min(176.573 ft³/min)Max.: 156 m³/min(5,509.088 ft³/min)
Operating pressure
800 mbar, 1,000 mbar(11.603 psi, 14.504 psi)
Nominal power
Min.: 10 kW(13.596 hp)Max.: 250 kW(339.905 hp)
Weight
Min.: 32 kg(70.55 lb)Max.: 1,150 kg(2,535.32 lb)
Length
Min.: 325 mm(12.8 in)Max.: 1,370 mm(53.94 in)
Depth
Min.: 206 mm(8.1 in)Max.: 625 mm(24.6 in)
Height
Min.: 170 mm(6.7 in)Max.: 710 mm(28 in)
