نام محصول:
کابل الکتریکی کواکسیال
نام انگلیسی:
Coaxial electrical cable T18
برند:
DJB Instruments UK Ltd
مشخصات:
1. Central conductor
2. Dielectric/ Insulation
3. Semi-conductive coating
4. Screen/ Outer conductor
5. Outer jacket
Conductor resistance: max 355Ω/km
Insulation resistance: >5000 MΩ x km
(Test voltage: 1 min: 3KV DC)
Capacitance: 105nF/km max
Weight: 8g/m
Attenuation: 108dB/100m
Bend Radius: Fixed 10mm, Flexing 20mm
RoHS Compliant – All Cables supplied by DJB Instruments UK Ltd and compliant with 2011/65/EU.
The facts and figures contained herein are carefully compiled to the best of our knowledge intended for
general information purposes only.
توضیحات:
Type
data, RF, audio/video
Format
coaxial
Protection
insulated
Configuration
stranded
Core material
copper
Nominal voltage
500 V
Temperature
Max.: 260 °C(500 °F)Min.: -90 °C(-130 °F)
