نام محصول:
پیش فیلتر هوا
نام انگلیسی:
Air pre-filter TVM series
برند:
LTG Aktiengesellschaft
مشخصات:
The LTG prefilter TVM is used for coarse filtration, in which a primary air flow loaded with fibers and coarse particles flows through a rotating filter medium whose mesh size is adapted to the particles. The filter medium is cleaned continuously by a fixed suction nozzle that does not touch the filter medium. The separated and extracted coarse components are then fed to a separator with a conveying fan in the secondary circuit.
For the multi-stage filtration of large air flows, flow-through screen meshes are advantageous for coarse filtration. These are characterized by the following properties:
• High air permeability
• Precise adaptation to the material to be separated through the use of different mesh sizes
• Relatively sharp separation
• Low-maintenance operation
The advantages of the LTG TVM pre-filter can be summarized as follows:
• Regenerative filter unit
• No pressure fluctuations in the extraction system thanks to continuous cleaning
• Space-saving installation thanks to the disk shape and compact design
• Optimum face velocity through precise adjustment to the total air volume
• Minimal soiling of the drive elements and easy access thanks to installation on the clean gas side
• Easy replacement of the filter medium
• Minimized pressure loss due to optimized flow routing
• Antistatic and ATEX versions available
توضیحات:
Designed for
air
Applications
coarse pre-filtration
Other characteristics
compact, ATEX
Operating pressure
Max.: 500 Pa(0.073 psi)Min.: 50 Pa(0.007 psi)
Filtration size
Max.: 1,000 µmMin.: 150 µm
Flow
Max.: 135,000 m³/h(4,767,480.007 ft³/h)Min.: 13,000 m³/h(459,090.667 ft³/h)
Fluid temperature
Max.: 200 °C(392 °F)Min.: 5 °C(41 °F)
