نام محصول:
پنل PC PV
نام انگلیسی:
PERC PV panel MS(390-410)MDG-40H
برند:
Maysun Solar
مشخصات:
1. The glass has the characteristics of zero water permeability, wear resistance, corrosion resistance, fire resistance, etc., so that the double-glass components can be widely used in various harsh environments and can continue to work for up to 30 years.
2.1.6mm ultra-thin double glass, with T6 ultra-narrow 28mm frame, weighing only 19.5KG, it is tailored for European distribution and easier to install.
3. Advanced 210mm large silicon wafer and 1/3 cutting battery technology, low current design, suitable for mainstream inverters in the market.
4. The black ceramic glaze combined with the black oxide anodized frame presents a perfect all-black appearance. At the same time, it can melt snow faster, which is more suitable for the Nordic frigid region.
More Details
1. The water resistance, weather resistance, corrosion resistance and wear resistance of glass exceed any known plastics, and can be widely used in harsh environments such as severe cold, high temperature, high humidity, salt spray, and ammonia gas. Double-sided glass and POE encapsulation materials make TwiSun components have super PID resistance and a 30-year service life.
2. 1.6mm+1.6mm tempered glass, plus ultra-narrow 28mm aluminum alloy frame, greatly reduces the weight of the module to 19.5kg, which is convenient for distributed system installation; the three-piece battery design allows the module to control the working current of about 10A , perfectly adapted to the current mainstream inverters in Europe.
توضیحات:
Material
monocrystalline silicon
Certifications
CE, IEC, ISO
Other characteristics
PERC, black, high-performance
Peak power (Wp)
390 W, 395 W, 400 W, 405 W, 410 W
Open-circuit voltage
40.8 V, 41 V, 41.2 V, 41.4 V, 41.6 V
Short circuit current
12.1 A, 12.2 A, 12.3 A, 12.4 A
Max power voltage
33.8 V, 34 V, 34.2 V, 34.4 V, 34.6 V
Max power current
11.5 A, 11.6 A, 11.7 A, 11.8 A
Module efficiency
20.3 %, 20.5 %, 20.8 %, 21.1 %, 21.2 %
Lenght
1,760 mm(69 in)
Width
1,098 mm(43 in)
Height
28 mm(1 in)
Weight
19.5 kg(42.99 lb)
