نام محصول:
پمپ
نام انگلیسی:
Oil pump PHN
برند:
CEPIC
مشخصات:
Anti-corrosion standardized horizontal centrifugal pumps type PHN
Construction
Single-stage horizontal centrifugal pump, single, in conformity to EN 22858 / ISO 2858 standards Sold either with unfitted cam shaft, or fitted with
coupling base plate and motor.
Our standardized PHN-type horizontal pumps with mechanical seals ensure the delivery of corrosive liquids with a flow rate of up to 700m3/h and a discharge head of 130 meters.
Options
Intermittent or continuous flushing
Specific fur material
Oil bearing lubrication
Dry running detector
ATEX construction according to 94/9/EC
ANSI flanges
Shaft sealing
Single reverse mechanical seal SiC-SiC or SiC-Carbon (spring out of fluid)
Double mechanical seal
Options
Intermittent or continuous flushing.
Specific fur materials.
Oil bearing lubrication
Dry running detector
ATEX construction according to 94/9/CE
Flanges ANSI
Benefits
Robustness
Insensitive to the direction of motor rotation
Easy maintenance (back pull-out)
No wheel nose
توضیحات:
Fluid
oil
Operation
with electric motor
Technology
centrifugal
Mobility
stationary
Domain
industrial
Applications
discharge, reverse
Protection level
anti-corrosion, ATEX
Other characteristics
mechanical, spring, double, single-stage, with mechanical seals, flow, dry, seal, ANSI
Flow
700 m³/h(24,720.26671 ft³/h)
Head
130 m(426’06” )
Power
200 kW(271.92 hp)
Fluid temperature
Max.: 165 °C(329 °F)Min.: -30 °C(-22 °F)
