نام محصول:
پمپ گرداب
نام انگلیسی:
Vortex pump Turo®
برند:
Emile Egger & Cie SA
مشخصات:
Turo® Vortex Pumps with a completely open spherical channel. Only 15% of the pumped fluid comes into contact with the impeller. Around the world, thousands of pumps have proven themselves with decades of excellent service.
Applications
– Municipal and industrial wastewater
– Every kind of sludge
– High concentrations of fibrous suspensions
– Chemical and crystalline suspensions
– All viscous materials
– Numerous abrasive and corrosive fluids
Features
– Gentle pumping of sensitive liquids and sensitive crystal structures
– Special volute casing, tuned to the hydraulics
– Big free passage even by small flow rates
Advantages
– Freedom from clogging by solids
– High, sustained efficiency
– Large, open spherical channel
– Reduced wear
– Low life cycle costs (LCC)
– Long service life (MTBF)
– Economic storage, thanks to its modular design
توضیحات:
Fluid
for wastewater, for industrial water, for cooling water, for chemicals, slurry, for food products, oil
Operation
electric
Technology
vortex
Mobility
stationary, mobile
Domain
industrial, for the chemical industry, for wastewater treatment, for the food industry, for the petrochemical industry, mining and quarrying, agriculture, for the construction industry, for the textile industry
Applications
transfer, process, cooling, circulation, irrigation, sewage, drain
Material
stainless steel, cast iron, titanium, nickel
Fluid specification
for aggressive media, for abrasive fluids, for solids-laden fluids, for low-viscosity fluids, for viscous fluids, for corrosive fluids, for high-purity fluids, for fluids with lubricating properties, for brine, for hazardous fluids, for flammable fluids, for paper stock, for refrigerant fluids, dye, for toxic fluids, for hot oil
Voltage
400 V, 380 V, 460 V, 110 V, 115 V
Protection level
abrasion-resistant, maintenance-free, explosion-proof, hazardous-duty, submersible, intrinsically safe
Other characteristics
single-stage, close-coupled, corrosion-proof, belt-drive, with gear reducer, fixed-speed, tandem, no-clog
Flow
Max.: 200 l/s(52.83441 us gal/s)Min.: 0 l/s(0 us gal/s)
Pressure
Max.: 30 bar(435.113 psi)Min.: 0 bar(0 psi)
Head
140 m(459’03” )
Fluid temperature
180 °C(356 °F)
Output diameter
Max.: 200 mm(7.874 in)Min.: 32 mm(1.26 in)
