نام محصول:
پمپ پیستون هیدرولیک
نام انگلیسی:
Hydraulic piston pump P1
برند:
Parker Stratoflex
مشخصات:
Parker P1 Medium Pressure Mobile Hydraulic Piston Pumps for open- circuit mobile applications increase productivity and improve the working environment with a robust cradle-bearing design, wide temperature range, full power thru-drive capability and an optional torque limiter. Featuring unique “ripple chamber” technology, PI variable displacement pumps minimize pressure pulsations and decrease noise. With lower power consumption and reduced heat, the series ensures reliable performance and efficient control.
Markets:
•Mobile
•Oil & gas
•Material Handling Equipment
•Agriculture Machinery
•Construction Equipment
•Forestry Equipment
•Other Mobile
•Turf Equipment
•Vocational and Municipal Equipment
•Bus & Coach
•On-Highway Vehicle (Not Bus/Coach)
•Rail
• – Transit Authority
Features and Benefits:
• – Increased productivity
• – Proportional electric Controls that provide flow on demand
• – Large stroking pistons for fast, stable response
• – Full power thru-drive capability
• – Improved reliability
• – Elastomer seals that eliminate gaskets and external leakage
• – Low friction cam and taper-roller shaft bearings
• – Industry-low viscosity capability
• – Design flexibility
• – Case drain port for horizontal or vertical shaft-up mounting
• – Optional maximum and minimum volume stops
• – End or side inlet and outlet ports
• – Small envelope size
• – Wide range of Controls
• – Ease of use
• – Low noise nine-piston design
• – Hydraulic Controls with “no leak” adjustments
توضیحات:
Type
piston
Operation
hydraulic piston
Material
cast iron
Applications
for industrial applications, for vehicles, handling, closed circuit
Other characteristics
compact, oil, low-noise, mobile, vertical
Pressure
280 bar(4,061 psi)
Flow rate
278 l/min(73.44 us gal/min)
Speed
Max.: 1,800 rpm(11,310 rad.min-1)Min.: 600 rpm(3,770 rad.min-1)
Weight
82 kg(180.78 lb)
