نام محصول:
پمپ هیدرولیک الکترولیک
نام انگلیسی:
Electro-hydraulic hydraulic pump
برند:
Zhejiang Dongzheng Motor Co., Ltd.
مشخصات:
HYDRAULIC OIL PUMP DC MOTOR GENERAL SPECS.
Voltage 12V DC ~ 48V DC
No-Load Speed 1000RPM ~ 9000RPM
Rated Output Speed 600RPM ~ 8000RPM
Rated Output Power 300W ~ 1500W
Insulation Class F
IP55, IP65, IP67 or IP69K
Customized shaft & front cover available upon request
Application: AGV, Automobile cab steering, Rising-lowering lifting system, Electric forklift, Lifting pump station, Hydraulic power leveling system etc.
توضیحات:
Operation
electro-hydraulic
Material
steel
Applications
for vehicles, water, fuel oil, for water treatment
Other characteristics
compact, oil, high-efficiency, heavy-duty, bidirectional, heavy-duty, waterproof, hydro-pneumatic
Speed
Max.: 9,000 rpm(56,549 rad.min-1)2,800 rpm(17,593 rad.min-1)Min.: 1,000 rpm(6,283 rad.min-1)
Weight
Max.: 3 kg(6.61 lb)2.5 kg(5.51 lb)Min.: 2 kg(4.41 lb)
Power
Max.: 1.5 kW(2.04 hp)0.6 kW(0.82 hp)Min.: 0.3 kW(0.41 hp)
