نام محصول:
پمپ نوشیدنی
نام انگلیسی:
Beverage pump
برند:
Diener Precision Pumps Ltd
مشخصات:
The Silencer Series gear pumps were designed from scratch to be everything a gear pump should be: durable, leak-free, reliable, chemically inert and quiet.
The Silencer Series precision gear pumps were designed from scratch to be everything a gear pump should be: durable, leak-free, reliable, chemically inert, and quiet. The robust helical gear design and simple construction translate to a low installed cost and durability that is second to none. The design is modular, meaning the series can cover a flow range of 50 ml/min to 6500 ml/min.
Inert materials of construction will withstand the most aggressive chemicals, and the magnetic coupling ensures no leaks.
The flow-thru design and low dead volume allow the pump to clean itself in a fraction of the time, a key benefit for food and beverage or medical applications where thorough clean-in-place is required. A low drive inertia allows rapid acceleration/deceleration and precision flow and pressure control. Three motor variants offer a wide range of electronic command options and the ability to generate very high pressures.
Its compact size allows it to fit into restricted spaces. Multiple port options/locations simplify plumbing and further reduces installation costs.
Benefits
Low Noise
Thanks to intelligent design and precision components, our pumps are the quietest of their kind. This makes them unbeatable when it’s important to have peace and quiet.
Long-life
DPP pumps are all characterized by their robustness and performance. Wear and tear is at its lowest, and their smart designs ensure a sustainable reduction in operating costs.
توضیحات:
Fluid
for chemicals, beverage
Operation
brushless DC
Priming
self-priming
Technology
gear
Mobility
stationary
Domain
chemical, for the food industry, laboratory, medical
Applications
transfer, dosing, for control, distribution, high-temperature, mixing, for precision applications
Material
stainless steel, EPDM
Fluid specification
for aggressive media
Protection level
chemical-resistant, robust
Other characteristics
compact, modular, low-pressure, micro, electronic, sensor
Flow
Max.: 6.5 l/min(1.71712 us gal/min)Min.: 0.05 l/min(0.01321 us gal/min)
Pressure
4 bar, 6 bar, 15 bar(58.015 psi, 87.023 psi, 217.557 psi)
Fluid temperature
Max.: 95 °C(203 °F)Min.: 0 °C(32 °F)
