نام محصول:
پمپ طبل
نام انگلیسی:
Drum pump VISCOPOWER F 570
برند:
FLUX-GERÄTE GMBH
مشخصات:
Pre-assembled progressive cavity pump kit with progressive cavity pump VISCOPOWER F 570 and planetary gear for industrial applications to pump thin to medium viscous media up to 30.000 mPas out of 200-l drums and IBCs. The positive displacement pump works smoothly at a constant pressure and ensures a gentle, pulsation-free pumping. Comprising progressive cavity pump VISCOPOWER F 570 in 1000 or 1200 mm, Commutator motor F 457, chemical and food hose, discharge spout, ressure connector adaptor and hinged clamp with seal and compression gland.
Technical data:
Viscosity: min. 1 mPas – max. 30000 mPas
Outer tube diameter: max. 53 mm
Immersion length: 1000, 1200
Materials outer tube: Stainless steel
Media / Fluids: Viscous media
Container: 1000 l IBC, 200 l drums
Product attributes
Positive displacement pump
Ideally suited to a wide range of low and medium viscosity industrial applications
Perfect for viscous, free-flowing media that is sensitive to shearing
Intuitive and quick to dismantle and clean
Smooth pumping and with very little turbulences
Low pulsation in relation to the flow
Pump / shaft / worm can be dismantled
Benefits
Wide range of viscosity can be covered
Optimal for viscous self-flowing media
Also suitable for shear-sensitive media
Transfer at constant pressure
Can be adjusted individually on the media’s characteristics
Pump can be dismantled
Efficient use of medium
High efficiency
توضیحات:
Fluid
for chemicals, for lubricants
Operation
electric
Technology
planetary gear
Mobility
stationary, mobile
Domain
industrial, chemical
Applications
transfer, drum, for industrial applications, IBC
Voltage
230 V
Other characteristics
with seal
Flow
Max.: 30 l/min(7.92516 us gal/min)Min.: 0 l/min(0 us gal/min)
Head
60 m(196’10” )
