نام محصول:
پمپ شیمیایی
نام انگلیسی:
Chemical pump 14520 series
برند:
Gorman-Rupp Industries
مشخصات:
Magnetic drive centrifugal pump operation is similar to a standard centrifugal pump except the motor shaft seal is removed resulting in the elimination of leaks caused by shaft seal failure. Magnetic drive centrifugal pumps must be used where flooded suction conditions exist.
GRI specializes in the custom design and manufacturing of fluid pumps for the OEM market. The chart below is a general overview of GRI’s Magnetic Drive Pumps. If you do not find a pump that meets your exact requirements, our dedicated Sales Team will work with you to create a solution specific to your application – whether it is customizing an existing pump or designing new.
Applications
Typical OEM Applications include, but are not limited to:
Fluid circulation, glycol, water
Medical
Chillers and coolers, coolant
Laser Systems
Alternative Power Units
Hydronic Systems
Recreational Vehicles and Public Transit
Marine
Alternative energy, Fuel Cells
Thermal heating and cooling
Beverage Dispensers
Printing and Imaging
Features
Corrosion resistant
Hydraulically efficient
No shaft seals
Low current draw and heat rise
Quiet operation
Flexible mounting and body discharge positions
NSF certified models available
توضیحات:
Fluid
for chemicals, fuel
Technology
centrifugal
Mobility
mobile
Domain
industrial
Applications
discharge, circulation
Material
EPDM
Voltage
24 V, 115 V, 230 V
Other characteristics
suction, standard, OEM, custom, heating
Flow
26 us gal/min(98.42071 l/min)
Pressure
75 psi
Head
35’00” (10.67 m)
Fluid temperature
95 °C(203 °F)
Length
256 mm(10 in)
Width
147.1 mm(5.79 in)
Height
130 mm(5.12 in)
