نام محصول:
پمپ دیافراگم
نام انگلیسی:
Diaphragm pump KLVP3 series
برند:
Kamoer Fluid Tech (Shanghai) Co.,LTD.
مشخصات:
KLVP3 series diaphragm air pumps are available in 24V and 12V voltages
The appearance of the product is personally checked by the design master, and it is beautiful and generous
Oil-free, maintenance-free, 24h uninterrupted work
Motors are optional, either cost-advantaged brushed motors or performance-advantaged brushless motors
Low noise, low power design
High-quality engineering plastics and rubber materials, showing good product stability
Applications
Environmental protection industry: such as use as a gas pump for gas monitoring
Medical equipment: such as used as an air pump for a rehabilitation instrument
Industrial automation: as a negative pressure pump for suction cups
White goods: such as use as a negative pressure pump for a massager
توضیحات:
Fluid
for chemicals, air, for gas
Operation
with brushless DC motor
Priming
self-priming
Technology
diaphragm
Mobility
stationary
Domain
industrial, medical
Voltage
24 V, 12 V
Protection level
maintenance-free
Other characteristics
suction, oil-free, brushless
Flow
1.2 l/min, 4 l/min(0.31701 us gal/min, 1.05669 us gal/min)
Pressure
0.05 MPa, 0.08 MPa
Power
2.5 W, 4 W(0 hp, 0.01 hp)
Fluid temperature
Max.: 40 °C(104 °F)Min.: 0 °C(32 °F)
Weight
80 g(2.82 oz)
