نام محصول:
پمپ دیافراگم

نام انگلیسی:
Diaphragm pump PD03P-XXS-XXX

برند:
ARO, Ingersoll Rand

مشخصات:
3/8” non-metallic diaphragm pump

The ARO nonmetallic 3/8” PD03P-XXS-XXX compact pump is a favorite of OEMs everywhere around the world. It is designed to be fully corrosion resistant. It has a polypropylene body, stainless steel fasteners and polypropylene, groundable acetal or PVDF casing materials.

It features a Simul-Shift valve technology that allows very reliable and ultra-positive signal. The unique ARO unbalanced valve integrated in this pump allows no stalls in operations. The outlet manifold is adjusted to your exact needs and it comes in three versions: center, dual inlet and end.

The modular design allows easy and comfortable use and maintenance and the bolted construction prevents any fluid leakage.

This pump can use a wide variety of accessories, including wall mount bracket, cycle counter kit, an air line connection kit with piggyback filter, regulator, pipe nipple and 5 sections of hose, cycle actuation kit and fluid section service kit.

The diaphragm is available in four materials: Hytrel, PTFE with Santropene backer, Santropene and Viton.

توضیحات:
Fluid
water, for chemicals, for food products, for lubricants

Operation
pneumatic

Technology
diaphragm

Domain
industrial, medical

Applications
for automatic machines, handling, for hazardous locations, transfer, for printing machines

Material
PVDF, polypropylene, plastic, PTFE

Fluid specification
for abrasive fluids, for hazardous fluids

Protection level
ATEX, hazardous-duty, abrasion-resistant, chemical-resistant

Other characteristics
OEM, compact, sensor, for circuits, suction, wall-mounted, standard, corrosion-proof, with seal, rugged, small, double, small-size

Flow
Min.: 0 l/min(0 us gal/min)Max.: 40.1 l/min(10.5933 us gal/min)

Pressure
Min.: 0 bar(0 psi)Max.: 6.9 bar(100.076 psi)
