نام محصول:
پمپ دوغاب
نام انگلیسی:
Slurry pump PE series
برند:
Pompes Japy
مشخصات:
Single-phase portable drainage pump
Descriptive
Specifications and advantages:
For the pumping of muddy and sandy water. Excavation drying.
Designed for prolonged dry running.
Temperature of the pumped liquid: 0 to 40°C.
230 V, 50 Hz single-phase motor with built-in heat protection and 10 m cable.
Maximum permitted particle size: Ø 6 mm.
Aluminium motor casing, stainless steel shaft, urethane turbine, waterproofing by a double mechanical seal with oil chamber.
Optional float.
توضیحات:
Fluid
water, slurry
Operation
electric
Priming
submersible
Technology
turbine
Mobility
stationary
Domain
industrial
Applications
drainage, drainage, lifting
Material
stainless steel
Fluid specification
for solids-laden fluids
Voltage
230 V
Other characteristics
mechanical, double, with mechanical seals, built-in, dry, portable, seal, thermal protection
Flow
12 m³/h, 18.5 m³/h(423.776 ft³/h, 653.32133 ft³/h)
Head
Max.: 18 m(59’00” )Min.: 12 m(39’04” )
Power
0.4 kW, 0.75 kW(0.54 hp, 1.02 hp)
Fluid temperature
Max.: 40 °C(104 °F)Min.: 0 °C(32 °F)
