نام محصول:
پمپ دنده
نام انگلیسی:
Gear pump GA
برند:
FLOWSERVE
مشخصات:
GA Series gear pumps have long been workhorses in highly viscous applications within a multitude of industries due to their dependability, efficiency and low total life cycle costs. Engineered to reliably pump viscous fluids over a broad range of flows and pressures, the GA Series’ superior between bearings, external gear design offers the benefits of pulse-free operation, dry-run capability and ease of maintenance.
Double helical, herringbone gears
Quiet, pulse-free flow
High-speed pump capability with off-the-shelf motors
Between bearings design
Self-lubricated babbitted carbon sleeve bearings standard; bronze bearings optional
Hydraulically balanced design requires no thrust bearings
Convertible stuffing box accommodates packing or mechanical seals
Threaded ports
Speeds to 1800 rpm
Viscosities to 5000 cP
General Industries
Other Industries
Biofuels
Midstream Transportation
Power
Combined Cycle
Concentrated Solar Power (CSP)
Biomass & MSW
توضیحات:
Fluid
for chemicals, oil, for gas
Operation
hydraulically-operated
Technology
gear
Mobility
stationary
Domain
industrial, for the food and beverage industry, for the paper industry, solar
Material
cast iron, bronze
Fluid specification
for viscous fluids
Other characteristics
mechanical, high-efficiency, double, low-noise, lubricated, high-speed, combined
Flow
27 m³/h(953.496 ft³/h)
Pressure
17 bar(246.564 psi)
Fluid temperature
175 °C(347 °F)
