نام محصول:
پمپ خلا پیچ
نام انگلیسی:
Screwdriver vacuum pump SSU-E
برند:
FIAM
مشخصات:
Vacuum pump required for screw suction in automatic pick & place applications. It works at 230Vac-50Hz / 120Vac-60Hz, and can be combined with the screw suction systems availables for eTensil screwdrivers and nutrunner motors.
Equipped with a screw presence detection device that automatically manages on/off for energy saving and noise reduction.
Entirely designed and manufactured by Fiam, is small and takes up little space on the workbench.
It connects not only to the TPU eTensil units but also to the PLC of the production site.
توضیحات:
Technology
piston
Lubrication
dry
Supply voltage
230VAC, 120 VAC
Number of stages
single-stage
Applications
suction, for industrial applications, for automation, for screwdrivers, table-top
Other characteristics
with electric actuator, electrically-powered
Ultimate vacuum
Max.: 0 bar(0 psi)Min.: -0.5 bar(-7.25 psi)
Flow rate
Max.: 25 l/min(6.6 us gal/min)Min.: 0 l/min(0 us gal/min)
Power
45 W(0.06 hp)
Operating temperature
20 °C(68 °F)Max.: 40 °C(104 °F)Min.: 0 °C(32 °F)
Length
210 mm(8 in)
Width
150 mm(5.91 in)
Height
140 mm(5.51 in)
Noise level
50 dB
Weight
3 kg(6.61 lb)
