نام محصول:
پمپ خلاء

نام انگلیسی:
Scroll vacuum pump GWSP series

برند:
GEOWELL VACUUM CO., LTD.

مشخصات:
oil free scroll vacuum pump, also refer to as vortex pump, dry scroll pump, oil free scroll pump, oilless scroll pump, dry scroll vacuum pump, oil free vortex vacuum pump is perfectly used in semiconductor industry, photoelectric, materials, medical, energy, aerospace, analyzing instruments and vacuum systems, with the advantages of compact structure, small size, light weight and low vibration, low noise, low energy consumption, suitable for global power supply, one button start, can be frequently started and stop between atmospheric pressure and vacuum.

GEOWELL is a professional manufacturer of scroll vacuum pumps with over 20 years of field experience, the longest performance hours and the largest sales in China, GEOWELL’s GWSP series scroll vacuum pumps are the premium choice for clean pumping technology.

توضیحات:
Technology
scroll

Lubrication
dry

Number of stages
single-stage

Other characteristics
compact, small, low energy consumption

Ultimate vacuum
0.01 mbar, 0.03 mbar, 0.06 mbar, 0.08 mbar(0 psi, 0 psi, 0 psi, 0 psi)

Flow rate
Max.: 71.6 m³/h(2,528.53 ft³/h)Min.: 3.6 m³/h(127.13 ft³/h)

Power
0.55 kW, 0.75 kW, 1.5 kW(0.75 hp, 1.02 hp, 2.04 hp)

Operating temperature
Max.: 104 °F(40 °C)Min.: 41 °F(5 °C)

Length
455 mm, 460 mm, 495 mm, 525 mm, 565 mm(18 in, 18 in, 19 in, 21 in, 22 in)

Width
260 mm, 310 mm, 325 mm, 445 mm(10.24 in, 12.2 in, 12.8 in, 17.52 in)

Height
275 mm, 320 mm, 335 mm, 405 mm(10.83 in, 12.6 in, 13.19 in, 15.94 in)

Noise level
57 dB, 60 dB, 61 dB, 63 dB
