نام محصول:
پمپ خلاء انتشار
نام انگلیسی:
Diffusion vacuum pump RTDP10
برند:
Shanghai Royal Technology Inc.
مشخصات:
The diffusion pump is used in vacuum coating system, optical coating machine, magnetron sputtering coating system, arc evaporation and thermal evaporation metallizing coaters; vacuum melting and drying system, also the vacuum furnace area for high temperature metallurgy.
Advantage:
1. Special designed cold trap unit and water – cooled device to guarantee low oil back- streaming rates into the vacuum chamber, avoid coating contamination.
2. Heating System: The heating cartridges are interior assemble, highly reduced the heating energy’s lost, reducing the warming-up time.
3. Pump body material: Stainless Steel 304, highly improved the ultimate vacuum pressure data, reducing raw material’s gasing – out in high vacuum pressure environment.
4. Cold trap: is with cooper material, U shape design, enhanced the frozing area.
5. Stable: working time up to 7200 hrs without stop;
6. Easy maintenance.
7. High Vacuum pumping speeds in the fine and high vacuum ranges, especially for optical and thermal evaporation coating system, keeping a stable vacuum range for base/working vacuum data.
توضیحات:
Technology
diffusion
Lubrication
lubricated
Supply voltage
220VAC
Number of stages
single-stage
Applications
machine, furnace
Other characteristics
stainless steel
Flow rate
1,600 l/s(422.68 us gal/s)
