نام محصول:
پمپ تجهیزات داخلی
نام انگلیسی:
Internal-gear pump TopGear Bloc
برند:
Johnson Pump
مشخصات:
Bloc Gear Pumps: Efficient, Economical, and Compact Pumping Solutions
TopGear Bloc pumps run on direct drive motor speed which means an economical solution for pumping low-viscosity and medium-viscosity, clean, non-abrasive media. It features a compact design for quick and easy installation in areas with limited space, eliminating the need for manual alignment of the pump and motor.
Why Choose Our Internal Gear Pumps?
Superior Efficiency: Engineered for low-to-medium viscosity liquids, ensuring optimal performance.
Compact Design: Ideal for installations with space constraints.
Perfect Alignment: The close-coupled design guarantees precise pump-motor alignment, enhancing service life.
Easy Maintenance: Simple pump design with minimal components for hassle-free upkeep.
CE Certified: Compliance with CE standards for quality and safety.
Discover the perfect blend of efficiency, reliability and compactness with our internal gear pumps. Designed to meet the diverse needs of various industries and applications, these pumps are designed for seamless operation and maximum durability.
Explore our range of models today and discover the ideal solution for your application.
Applications
With close-coupled IEC electric motors, TopGear Bloc gear pumps are ideal for scenarios where space is at a premium, such as OEM equipment and shipbuilding.
Our positive displacement internal gear pumps are perfect for:
Lubrication Oil
Fuel Oil
Bio-Fuel
Chemical Additives
Food Oils
Solvents
Glycol
توضیحات:
Fluid
for food products, fuel
Operation
manual
Technology
internal-gear
Mobility
stationary
Domain
industrial
Material
stainless steel, cast iron
Fluid specification
for low-viscosity fluids, for medium-viscosity products
Protection level
robust
Other characteristics
compact, close-coupled
Flow
Max.: 50 m³/h(1,765.73334 ft³/h)Min.: 0 m³/h(0 ft³/h)
Pressure
Max.: 16 bar(232.06 psi)Min.: 0 bar(0 psi)
Fluid temperature
180 °C(356 °F)
