نام محصول:
پمپ بازیافت
نام انگلیسی:
Recovery pump MEX series
برند:
DÜRR TECHNIK
مشخصات:
Our innovative vapour recovery pumps ensure safe use at filling stations all over the world. No matter whether you use belt drive or direct drive – we have the right products for vapour recovery.
Please contact us and we will be glad to discuss your requirements.
Your advantages at a glance
Reliable & durable
High quality through Made in Germany
Certified according to ATEX (2014/34/EU), TÜV, QS, PTB and PCEC
Economical thanks to long service life
Safe & robust
Integrated flame arresters on the inlet and outlet side for maximum safety
Also suitable as flame arrester in GR systems
Explosion protection according to ATEX
Self-adjusting piston seal for a constant volume flow over the entire service life
Patented prechamber with drainage system ensures insensitivity to condensate and liquid
Constant volume flow during the entire service life of the vapour recovery pump
توضیحات:
Fluid
condensate, for gas
Operation
with electric motor
Technology
piston
Mobility
stationary
Domain
industrial, for the petrochemical industry
Applications
recovery
Voltage
380 V, 24 V
Protection level
explosion-proof, ATEX
Other characteristics
rugged, belt-drive, direct-drive, with electronic control, with speed controller, self-adjusting
Flow
Max.: 860 l/min(227.18797 us gal/min)44 l/min(11.62357 us gal/min)Min.: 25 l/min(6.6043 us gal/min)
Pressure
Max.: 150 mbar(2.176 psi)150 mbar(2.176 psi)Min.: 0 mbar(0 psi)
Power
Max.: 2,000 W(2.72 hp)150 W(0.2 hp)Min.: 0 W(0 hp)
Length
Max.: 489 mm(19 in)Min.: 117 mm(5 in)
Width
88 mm, 160 mm, 174 mm, 176 mm(3.46 in, 6.3 in, 6.85 in, 6.93 in)
Height
188 mm, 201 mm, 209 mm(7.4 in, 7.91 in, 8.23 in)
