نام محصول:
پمپ اب
نام انگلیسی:
Water pump HC T54338002F0
برند:
Shenzhen Hungsung Weiye Electronic Technology Co., Ltd.
مشخصات:
1. Long life
2. High chemical risistance
3. Low noise
4. Maintenance-free
5.small size
6. Self-priming
7. Dry loaded
8.Oil-free
9. No leaking
10 .high efficiency
11. Suitable for liquid and liquid/gas
12. Brushless motor
Material:
Pump head: PA66 Vales: EPDM Diaphragm: EPDM
四．Application
• Medical diagnostics
• Inkjet printing
• Fuel cells
• Semi conductor industry
• Water analysis
توضیحات:
Fluid
water, fuel
Operation
brushless DC
Priming
self-priming
Technology
diaphragm
Mobility
stationary
Domain
industrial, chemical, medical
Material
EPDM
Voltage
24 V, 12 V
Protection level
IP55
Other characteristics
dry
Flow
0.6 l/min, 1 l/min(0.1585 us gal/min, 0.26417 us gal/min)
Pressure
0.06 MPa
Head
12 m(39’04” )
Input diameter
Min.: 1.5 mm(0.059 in)Max.: 4 mm(0.157 in)
Output diameter
Min.: 3 mm(0.118 in)Max.: 6 mm(0.236 in)
Weight
0.3 kg(0.66 lb)
