نام محصول:
پمپ اب
نام انگلیسی:
Water pump FP Series
برند:
Pierre GUERIN
مشخصات:
MODEL :
As constructor of pump systems, Pierre Guérin has developed together with the PACKO Inox Company a complete range of centrifugal pumps. The PCP–FP series is dedicated to the Food & Beverage industry and designed to meet the highest requirements with regards to cleanability: all models are made from Stainless steel EN 1.4404 (316 L) with electro-polished finishing and are certified according to the EEC directives.
The PCP pumps are suitable for the transfer of liquid product with viscosity up to 1 000 cpo such as: milk, wines and alcohols, waters, fruit juices, oils, sugar syrups, cleaning solutions.
Performances of the PCP–FP series:
• FP6 series: up to 35 m3/h – 2.5 bar – 3.8 kW
• FP2 series: up to 95 m3/h – 12 bar – 22 kW
• FP3 series: up to 700 m3/h – 12 bar – 90 kW
Maximum temperature: EPDM 130°C – VITON 200°C – FEP 250°C.
APPLICATIONS :
– User Benefits –
• EEC compliant
• perfect clean in-place performance thanks to electro-polished finishing, open wheel design (FP2 / FP6 series) and large seal chamber ensuring maximum turbulences during CIP
• unique design allowing for the choice of 2 interchangeable types of mechanical seals: internal mechanical seal with spring with or without product contact
• mechanical seal compliant to DIN, ISO and AFNOR standards with minimum sensibility to over pressure and water hammervery low acoustic level
• very low acoustic level
• minimum NPSH required
• limited number of spare parts needed.
DESCRIPTION :
Packo centrifugal pumps for the Food & Beverage industry.
APPLICATIONS :
Transfer of any low viscosity liquid including milk, wines and alcohols, beer, fruit juices, oils, waters, sugar syrups, cleaning solutions, etc.
توضیحات:
Fluid
water, for food products, oil, beer
Operation
electric
Technology
centrifugal
Domain
for the food and beverage industry
Applications
transfer
Material
stainless steel
Other characteristics
with open impeller
Flow
35 m³/h, 95 m³/h, 700 m³/h(1,236.01334 ft³/h, 3,354.89334 ft³/h, 24,720.26671 ft³/h)
Pressure
2.5 bar, 12 bar(36.259 psi, 174.045 psi)
Power
3.8 kW, 22 kW, 90 kW(5.17 hp, 29.91 hp, 122.37 hp)
