نام محصول:
پمپ اب
نام انگلیسی:
Water pump BN series
برند:
Hayward Tyler®
مشخصات:
Axial Mixed Flow Pumps
Vertical, wet pit design pump for Circulating Water Service (including condenser). Specifically designed for the nuclear industry, it features a number of hydraulic designs, and is engineered to fit customer requirements.
Design Features of Hayward Tyler Axial Mixed Flow Pumps:
Hayward Tyler offers various, wet pit designed pumps that are ideal for applications where large flow capacities at relatively low heads are required. This includes Circulating Water Service (including condenser).
Cast or fabricated discharge head located above or below floor
Back-pull out design for ease of maintenance
Balanced hydraulics reduces thrust loading
Replaceable shaft sleeves with hardened material
Bearing span optimized to avoid excitation
Vertical rigid adjustable coupling allows axial adjustment
Multiple material choices to match application
Applications
Hayward Tyler Axial Mixed Flow Pumps are ideal for the following applications:
Cooling Water
Condenser Circulating Water
Circulating Water
توضیحات:
Fluid
water
Operation
electric
Priming
semi-submersible
Technology
impeller
Domain
industrial, for the nuclear industry
Applications
discharge, cooling, service
Other characteristics
axial, adjustable, large, vertical
Flow
Min.: 0 us gal/min(0 l/min)Max.: 178,000 us gal/min(673,803.29755 l/min)
Head
Min.: 0’00” (0 m)Max.: 152’00” (46.33 m)
