نام محصول:
پمپ اب
نام انگلیسی:
Water pump NM, NMD
برند:
Calpeda
مشخصات:
Construction
Close-coupled, centrifugal pumps; electric motor with extended shaft directly connected to the pump.
NM: single-impeller.
NMD: with two back-to-back impellers (with axial thrust balancing).
Connections
: threaded ports ISO 228/1 (BS 2779).
NM, NMD: version with pump casing and lanter bracket in cast iron.
B-NM, B-NMD: version with pump casing and lanter bracket in bronze (the pumps are supplied fully painted).
Applications
– For clean liquids without abrasives, which are non-aggressive for the pump materials (solids content up to 0.2%).
– For water supply.
– For heating, air-conditioning, cooling and circulation plants.
– For civil and industrial applications.
– For fire fighting applications.
– For irrigation.
توضیحات:
Fluid
water
Operation
electric
Technology
centrifugal
Domain
industrial
Applications
firefighting, irrigation, circulation, for air conditioning, transfer
Material
cast iron
Other characteristics
close-coupled, for heating
Flow
Max.: 66 m³/h(2,330.768 ft³/h)Min.: 1 m³/h(35.31467 ft³/h)
Head
Max.: 114 m(374’00” )Min.: 3.5 m(11’05” )
Power
Max.: 9.2 kW(12.51 hp)Min.: 0.37 kW(0.5 hp)
