نام محصول:
واحد فیلتراسیون فشار سری ALF

برند:
Alfa Laval

نام انگلیسی:
Pressure filtration unit ALF series

مشخصات:
Technology
pressure

Designed for
for water

Other characteristics
automatic, self-cleaning, cooling, basket

Flow
Max.: 2,000 m³/h (70,629.333 ft³/h)
Min.: 0 m³/h (0 ft³/h)

Pressure
Max.: 0.5 bar (7.25 psi)
Min.: 0.01 bar (0.15 psi)

توضیحات:
The Alfa Laval Filter (ALF) constitutes of a range of automatically self-cleaning filters/strainers, used mainly to protect heat exchangers from clogging, fouling and corrosion in various industries where cooling systems use low-quality water. ALF removes debris and marine life, reducing the risk of unplanned downtime and prolonging heat exchanger service intervals.

ALF is a pressure filter designed to maintain the thermal performance of plate heat exchangers and tubular condensers by making sure there is no debris or other undesirable materials in the water used in secondary cooling systems, via a highly effective automatic flushing set-up. Secondary cooling systems that use inexpensive, low-grade water have become widely accepted in industry, on ships and offshore installations, petrochemical plants and refineries, in power plants and in district heating and cooling systems. However, such water often contains undesirable particles, organisms and debris that can foul and clog the plate heat exchangers or tubular condensers used in such cooling set-ups.

Increase efficiency – protecting against clogging & fouling
Fouling, clogging and corrosion can have serious effects, reducing the efficiency of heat transfer and limiting the speed at which water can flow through the heat exchanger. This results in conditions in which biological growths can flourish, and surface fouling caused by diminished flow velocities.

The Alfa Laval Filter (ALF) is a supremely cost-effective way to avoid all these problems and ensure a reliable supply of clean cooling water.
