نام محصول:
میکرو پمپ
نام انگلیسی:
Micro pump TL-B10
برند:
TOPSFLO INDUSTRY AND TECHNOLOGY CO., LIMITED
مشخصات:
Product Features:
1.Advanced magnetic driving technology for static-seal, without any leakage forever
2.Durable permanent magnetic rotor with one-off injection incorporated impeller in smooth balance
3.Heavy duty work, can sustain continuous 24 hours work
4.Special designed high efficiency closed-type impeller
5.Sustain 100°C hot water circulation
6.All wetted materials FDA approved to be safety usage
7.Low or no maintenance
8.Can customized
9.IP protection level IP68
Protection Function
Blocked-Protection
Polarity Protection
Custom function
Over-Current Protection
Dry-running Protection
Over-voltage protection
Typical Applications
• Battery cooling water pump
• Truck air conditioning cooling
• Water dispenser, Water Coolers pump,hot water dispenser
• Carbonation, Coffee Maker, Beverage Dispenser
• Air-conditioner Drain
• Chillers, 3D printer Cooling Circulation
• Home Appliance Boosting
• Evaporative coolers
• Air Purifying Humidifier
• E-mobility chargers,EV charger cooling
Get More
http://www.topsflo.com/brushless-dc-pump/brushless-dc-pump.html
توضیحات:
Fluid
for hot water, for cooling water, beverage
Operation
with brushless DC motor
Technology
centrifugal
Mobility
stationary
Domain
for the food industry, for automotive applications, air conditioner
Voltage
24 V, 12 V
Other characteristics
compact, dry, mini pump, with closed impeller, micro, battery-powered
Flow
7 l/min, 9 l/min, 12 l/min(1.8492 us gal/min, 2.37755 us gal/min, 3.17006 us gal/min)
Head
3 m, 5 m, 8 m(9’10” , 16’04” , 26’02” )
Power
Min.: 7 W(0.01 hp)Max.: 32 W(0.04 hp)
Fluid temperature
Min.: -10 °C(14 °F)Max.: 100 °C(212 °F)
Input diameter
17.5 mm(0.689 in)
Output diameter
10.5 mm(0.413 in)
