نام محصول:
منبع تغذیه AC/DC
نام انگلیسی:
AC/DC power supply ADC
برند:
Benning
مشخصات:
Electronic equipment for the process and transportation industries as well as for telecommunication, power generation and distribution utilities are using microprocessors and require continuous DC power in the event of mains failure or mains disturbances.
The new BENNING ADC rectifier line with its modular and compact design represents a perfect solution for a wide range of applications in the industrial and telecommunication market.
General Features
switched-mode rectifier
19″ module
circuit-design
digital controller
Maximum Availability
extensive signalling and monitoring function
different operating modes available
temperature-controlled charging
battery availability test / battery circuit test
galvanically isolated
high quality of output power (parameters)
Highest Economic Efficiency
low residual ripple at rectifier output
low THD (total harmonic distortion)
suitable for lead and NiCd batteries
low volume and weight
easy adaptation of system power
low-cost “all-inclusive” system
plug and play
توضیحات:
Type
AC/DC
Technology
switching
Mounting
wall-mount
Certifications
ISO
Features
compact, modular
Applications
for industrial applications, for telecommunications equipment
Other characteristics
redundant, robust, stand-alone
Input voltage
Min.: 93 VMax.: 264 V
Output voltage
Min.: 12 VMax.: 220 V
Power
Min.: 300 WMax.: 2,400 W
