نام محصول:
مفصل دوار آب
نام انگلیسی:
Water rotary joint QCN0201-85-08P-04S-02EG
برند:
CENO Electronics technology Co., Ltd
مشخصات:
CENO air rotary union can pass compress air, nitrogen and so on. The rotary union contains two precise bearings, they share a smooth and lasting high-speed running with firmness and flexibility. With many advantages long life, rapid delivery, transmit100M/1000M Ethernet, integrate various signal, anti-interference. Pneumatic, hydraulic channel are all able to use connector to do connection, convenient to on-site installation.
• Current : 8*30A;4*2A;2 group Driver-cliq Ethernet encoder signal
• Voltage : 380VAC/VDC
• Insulation resistance :
≥500MΩ@500VDC(current)
≥100MΩ@100VDC(signal)
• Dielectric strength : –
≥1500V@50hz(current)
≥500 V@50hz(signal)
• Resistance fluctuation : ≤10mΩ(with50rpm)
• Contact Material : Precious Metals
• Operating temperature : -20℃~+60℃
• Channel number : 2
• Connector size : G1/8
توضیحات:
Medium
for water, for air, for gas
Number of passages
2-passage
Applications
hydraulic, pneumatic, for rotary tables
Other characteristics
high-speed, with electrical slip ring
Rotational speed
Min.: 0 rpm(0 rad.min-1)Max.: 150 rpm(942.48 rad.min-1)
Pressure
500,000 Pa(73 psi)
Nominal size
8 mm(0.315 in)
