نام محصول:
محرک روتاری
نام انگلیسی:
Rotary actuator AS series
برند:
UFLOW AUTOMATION
مشخصات:
Uflow has successfully developed Compact, Patented Aluminium Free Rack & Pinion Pneumatic Rotary Actuator, Consuming Low Volume of Air.
Wear proof aluminium free Rack & Pinion design.
Smooth travelling stroke for extending the life of ball valve sheet.
Low air consumption with maximum torque due to compact design.
Finer teeth module for smoother operation, and jerk-free sliding.
Providing a hard-anodized body for high corrosion resistance.
Maintenance-free design.
توضیحات:
Movement
rotary
Type
pneumatic
Technology
rack-and-pinion
Configuration
single-acting
Material
anodized aluminum
Protection class
maintenance-free
Other characteristics
compact, maintenance-free, low air consumption
Pressure
8 bar(116.03 psi)
Rotation angle
Max.: 90 °Min.: 0 °
Ambient temperature
Max.: 125 °C(257 °F)Min.: -60 °C(-76 °F)
