نام محصول:
فیلتر گاز AFP-AZ Comfort
برند:
MANN+HUMMEL Air Filtration
نام انگلیسی:
Gas filter AFP-AZ Comfort
مشخصات:
Designed for
gas
Filtration element
pocket, activated carbon
Filtration method
absorption
Applications
low-pressure
Other characteristics
compact, V-form
Flow
Max.: 3,400 m³/h (120,069.867 ft³/h)
Min.: 850 m³/h (30,017.467 ft³/h)
Operating pressure
Max.: 130 Pa (0.019 psi)
Min.: 17 Pa (0.002 psi)
توضیحات:
AFP-AZ Comfort gas adsorption filters are an excellent, inexpensive method for removing odours and improving indoor air quality in air-conditioned buildings – an important contribution to the cure of “sick building syndrome” (SBS). AFP-AZ Comfort are designed to remove contaminations which can cause unpleasant physical reactions of the occupants, e.g. headaches and nausea.
Gaseous, odourous compounds can be fed into room air from a car or airplane exhaust, or alternatively they may occur due to material emissions and processes indoors. AFP-AZ Comfort removes such compounds and purifies the air by making use of a high-quality activated carbon composite material. The composite material is based on fine grain granular adsorbents embedded into a synthetic textile matrix.
Fitting into standard fine dust filter frames, AFP-AZ Comfort can be used to supplement current mechanical particulate filters.
Features
Nominal air flow of 3400 m³/h per cell
Suitable for environments with high air flows requirements
Low pressure drop
Lowers energy consumption and operating costs
Large filter surface of 10 m²
For a longer life and high retention capacity
Activated carbon composite material
No dust generation
Fully incinerable, plastic cavity profile frame
For simple, environmentally-friendly disposal
Lightweight
Simplifies handling, installation and removal
Compact – installation depth only 300 mm
Installed in standard bag filter framework
Self supporting and rigid
For reliability in operation
