نام محصول:
فیلتر هیدروژن
نام انگلیسی:
Hydrogen filter TSF2 H2
برند:
TSF2 H2
مشخصات:
Contaminants in the gas flow can enter the vehicle‘s storage tank during refueling. These dirt particles in the hydrogen fuel may cause damage to the sealing components. WEH, therefore, offers the WEH® TSF2 H2 Filter Series for clean hydrogen.Solid particles are captured reliably.
The filter element can be removed and is re-usable after having been cleaned.
The WEH® TSF2 H2 Filter is mainly used for fueling stations and dispensers.
In order to meet the different requirements of the dispenser manufacturers, WEH offers a wide variety of connection configurations – tube fitting / female thread on both ends or internal and male thread.
For use as a prefilter in the WEH® TSA2 H2 Inline Breakaway Coupling, WEH offers a special design with external and female thread.
توضیحات:
Designed for
gas
Filtration element
cartridge
Applications
for fueling stations
Material
stainless steel
Mounting
screw-lock
Fluid specification
hydrogen
Other characteristics
in-line, corrosion-proof
Operating pressure
35 MPa, 45 MPa
Filtration size
20 µm, 40 µm
Fluid temperature
Max.: 85 °C(185 °F)Min.: -40 °C(-40 °F)
