نام محصول:
فیلتر هیدرولیک
نام انگلیسی:
Hydraulic filter KDF-W
برند:
KDF-W
مشخصات:
Duplex filter DN15-1000 / ½“-40“ with smooth ball valve switching
Tailor made customized solutions (e.g. special closures or heating jacket)
Made of Steel, Stainless steel, GRP and more
The KDF duplex filter can be used universally as a coarse and fine filter on the suction or on the pressure side. Filter operation is maintained without interruptions during the cleaning phase. The double filter is cast as one part consists of two identical single filters which can be operated alternatively or in parallel via a changeover fitting.
The single filter consists of a cast or welded body, cover and filter insert. The filter insert is a basket strainer made of perforated sheet metal covered with a mesh made of different materials and mesh sizes. The medium to be filtered enters the filter from above, generally flowing through the insert from the inside outward. Impurities are caught in the strainer insert, accordingly.
توضیحات:
Designed for
hydraulic
Filtration element
double-basket
Filtration method
pressure
Applications
suction, fine
Material
stainless steel, steel
Other characteristics
duplex
Operating pressure
16 bar(232.06 psi)
Filtration size
Min.: 10 µmMax.: 1,000 µm
Flow
Min.: 5 m³/h(176.573 ft³/h)Max.: 162 m³/h(5,720.976 ft³/h)
