نام محصول:
فیلتر هوا
برند:
Copes-Vulcan
نام انگلیسی:
Air filter NG-187
مشخصات:
Designed for
air, dust
Filtration element
panel
Filtration method
pressure
Applications
safety
Material
metal
توضیحات:
NG-187
Product Category:
SINGLE & TWO STAGE FILTERS
Dollinger Single Stage Air Intake Filter NG-187
The Dollinger NG-187 single stage air intake filter is designed to efficiently and economically remove dust, dirt and other airborne contaminants from the atmosphere in a single stage panel filter element protecting, high efficiency turbo blowers & axial compressors, while reducing noise to within OSHA established limits.
Dollinger manufactures 18 standard models, available with ranges from 3,000 to 72,000 SCFM and bottom outlets ranging in size from 6″ to 36″ in diameter. The optional silencing feature provides sound attenuation up to 16 dB(A).
Housing Design and Construction
The rigid, all weather galvannealed housing of the NG-187 provides strength and corrosion resistant protection on outdoor installations. All surfaces are finished with a coat of blue hammertone enamel for long life and durability. Weatherhoods are provided as standard equipment.
All metal joints of the NG-187 are welded and sealed as required to prevent dust from entering the unit. The standard conical safety screen over the filter outlet prevents small foreign objects from entering the exposed air intake passage when servicing or replacing panel elements. A ¼” pressure tap attachment is standard on each housing for regular monitoring of system pressure drop.
The filter housing may also be modified or customized to meet special application needs.
ELEMENT DESIGN AND CONSTRUCTION
The single-panel element design of the Dollinger NG-187 provides clean air with low pressure loss and highremoval efficiency. No special tools or parts are required to replace or service Dollinger panel elements.
