نام محصول:
فیلتر هوای فشرده
نام انگلیسی:
Compressed air filter NL
برند:
NL
مشخصات:
Capacity Range: 125-10000 cfm (3.5-283.2 m3/min) Filtration Grades: High efficiency Pressure Drop: 0.5 psig (0.03 barg) Maximum Operating Pressure: 150 psig (10.3 barg) Maximum Operating Temperature: 125°F (52°C) Minimum Operating Temperature: 34°F (1°C) Element Life: 10 years
Efficient Equipment Protection: High-efficiency particulate filtration to 0.5 ppm, > 3 microns at 100%, between 0.1 to 3 microns at 99.98%
Lower Energy Use: Low pressure drop design saves on energy costs and provides an economical drying solution for your compressed air needs
Extend Equipment Life: High-quality, maintenance-free filters extend element life up to 15 years
Maximize Uptime: Reduces the effects of catastrophic air/oil separator failures
Effective Operation: Works on all common mineral and synthetic lubricants
توضیحات:
Designed for
compressed air
Filtration element
cartridge
Filtration method
coalescing
Applications
low-pressure
Mounting
threaded, flange
Other characteristics
high-efficiency, low pressure
Operating pressure
Max.: 150 psiMin.: 0 psi
Filtration size
Max.: 3 µmMin.: 0.1 µm
Flow
Max.: 10,000 ft³/min(283.168 m³/min)Min.: 125 ft³/min(3.54 m³/min)
Fluid temperature
Max.: 52 °C(125.6 °F)Min.: 1 °C(33.8 °F)
