نام محصول:
فیلتر هوای فشرده
نام انگلیسی:
Compressed air filter MFM – MFS – MFC series
برند:
MFM – MFS – MFC series
مشخصات:
Micro air filters eliminate various harmful agents, solid particles, liquid particles and oil aerosols contained in compressed air, with a filtration efficiency greater than 99.999%.
They guarantee high-quality air with low pressure drops.
Micro air filters are designed and constructed to:
– Deliver the level of filtration required to ensure quality work
– Extend element service life
– Lower pressure drops
– Ease installation and maintenance
G 1/4 to G 3 tapped connections
Micro air filters are made using 100% silicone-free material.
The combination of oil, dust and water in compressed air is extremely corrosive.
These contaminants can damage air systems, pneumatic tools, and the resulting quality of work.
– MFM filters: Mechanical filtration
– MFB filters: Submicron coalescing filtration
– MFC filters: Activated carbon filtration
توضیحات:
Designed for
compressed air
Filtration element
cartridge, activated carbon
Other characteristics
low pressure, silicone-free, micro-flow
Operating pressure
Min.: 0 bar(0 psi)Max.: 20 bar(290.075 psi)
Filtration size
0.01 µm, 1 µm
Flow
Min.: 0 m³/h(0 ft³/h)Max.: 34 m³/h(1,200.699 ft³/h)
Fluid temperature
Min.: 3 °C(37.4 °F)Max.: 80 °C(176 °F)
