فیلتر هوای فشرده – – Compressed air filter

نام محصول:
فیلتر هوای فشرده

نام انگلیسی:
Compressed air filter

برند:

مشخصات:
Three times the fil­ter area with the same con­struc­tion vol­ume

Com­pared to fil­ter ver­sions with round tubes, car­tridge fil­ters of­fer three times the fil­ter area with the same con­struc­tion vol­ume, en­abling a re­duc­tion in in­vest­ment and op­er­at­ing costs. Car­tridge fil­ters are typ­i­cally used as in­take fil­ters for cen­tral com­pressed-air sys­tems and in bag­ging and pack­ag­ing plants used, for ex­am­ple, in the plas­ter and dry mor­tar man­u­fac­tur­ing in­dus­try.

Pipe car­tridge fil­ters are the pre­ferred choice when de­dust­ing low vol­u­met­ric flows (200 to 500 m3/​h) with fine, free-flow­ing and ex­tremely dry dusts in ad­di­tive si­los, bag­ging sta­tions and man­ual dosers. The pres­sure shock-proof ver­sions (10 bar) are the per­fect so­lu­tion for pre-hop­per de­dust­ing in pneu­matic con­veyor sys­tems.

Safety fil­ters with a car­tridge fil­ter de­sign are used for pro­tect­ing com­po­nents con­nected down­stream of a main fil­ter (such as com­pres­sors). As a re­sult, these units are also pro­tected in the event that larger quan­ti­ties of dust en­ter the clean gas stream in the main fil­ter be­cause of dam­age to the tube, for ex­am­ple.

توضیحات:
Designed for
compressed air, dust

Filtration element
cartridge

Other characteristics
high-capacity

Operating pressure
10 bar(145.038 psi)

Flow
Max.: 500 m³/h(17,657.333 ft³/h)Min.: 200 m³/h(7,062.933 ft³/h)
