نام محصول:
فیلتر آب
نام انگلیسی:
Water filter AG200 series
برند:
AG200 series
مشخصات:
Versatile automatic filters, Hectron AG range filters are available with filtration thresholds from 0.5 to 500 microns. The suction-ramp washing system offers high efficiency with low water consumption.
The cleaning system is triggered by measuring the pressure difference between the upstream and downstream; the cleaning frequency automatically adjusts according to the water load.
These models are supplied ready to use, with an automatic control system.
The AG200 is available in a wide range of versions and options.
Available versions
316L stainless steel: All filter parts are made of either plastic or 316L stainless steel.
Marine: The body is made of Rilsan-coated 316 stainless steel, with water-contact parts in Duplex stainless steel or plastic.
Options
Microfiltration: 0.5 or 1µm membrane: excellent turbidity reduction
Cleaning mechanism and specific operating constraints
ACS: ACS certified version (Sanitary Conformity Certificate)
For use on potable water networks
PN10: Maximum operating pressure: 10 bar
A suction pressure limiter automatically regulates the pressure in the cleaning manifold.
PN16: Maximum operating pressure: 16 bar
Pressure limiter
Reinforced casing
90°C: Maximum water temperature: 90°C
Electrical components thermally insulated from the casing
IP65: Enhanced sealing on the electrical components
توضیحات:
Designed for
water
Filtration element
strainer
Filtration method
pressure
Applications
industrial, fine, for water treatment, safety, irrigation, for cooling towers, for boreholes
Material
stainless steel
Cleaning
backwash, self-cleaning
Fluid specification
sewage treatment, for rinse water, for potable water
Other characteristics
automatic
Operating pressure
Max.: 16 bar(232.06 psi)Min.: 2 bar(29.008 psi)
Filtration size
Max.: 200 µmMin.: 1 µm
Flow
Max.: 45 m³/h(1,589.16 ft³/h)Min.: 25 m³/h(882.867 ft³/h)
