نام محصول:
غده کابل پلی آمید
نام انگلیسی:
Polyamide cable gland RM series
برند:
TAKACHI Electronics Enclosure Co., Ltd.
مشخصات:
■ Low cost cable glands made from polyamide material.
■ Wide selection, for M8 ~ M63, suitable for Φ1mm ~ Φ44 mm cable.
■ High oil resistant NBR rubber sealing and O-ring.
■ IP67 protection class.
Technical Data
Protection class: IP67
Operating temperature: -20°C ~ +80°C
■ DXF/DWG/PDF drawings available on our website.
■ Lock nut is not included for RM8S-2.5, 8S-4, and 10S-6 models.
Please drill a proper thread hole into the enclosure for installation.
توضیحات:
Material
polyamide
Protection level
IP67
Other characteristics
threaded, straight
Cable diameter
Max.: 44 mm(1.73 in)Min.: 1 mm(0.04 in)
Thread diameter
Max.: 63.4 mm(2.5 in)Min.: 8.2 mm(0.32 in)
Operating temperature
Max.: 80 °C(176 °F)Min.: -20 °C(-4 °F)
