نام محصول:
غده کابل پلاستیکی
نام انگلیسی:
Plastic cable gland DAK 284
برند:
STEGO
مشخصات:
Passive pressure compensation element for the safe insertion of cables into a casing. Levels temperature-induced pressure differences between the inside and outside of the enclosure. Air humidity escapes through a waterproof filter. The formation of condensate is prevented.
Thread sizes: M12, M16 and M20
NBR sealing gasket
Water and dirt-proof
Protection type IP66 / IP67
توضیحات:
Material
plastic
Protection level
IP66, IP67
Other characteristics
ventilation
Cable diameter
12.3 mm, 16.3 mm, 20.3 mm(0.48 in, 0.64 in, 0.8 in)
Thread diameter
Max.: 26 mm(1.02 in)Min.: 18 mm(0.71 in)
Operating temperature
Max.: 80 °C(176 °F)Min.: -20 °C(-4 °F)
