نام محصول:
صفحه پیچ APACHE ®
نام انگلیسی:
Screw screen APACHE ®
برند:
ESTRUAGUA
مشخصات:
Type
screw
Applications
for wastewater treatment
توضیحات:
Characteristics: Specially designed for those spillways or storm tanks of not very high flows or dimensions.
Characteristics:
Specially designed for those spillways or storm tanks of not very high flows or dimensions.
Excellent QUALITY/PERFORMANCE/PRICE relation.
Robust construction totally in stainless steel Aisi 304 or 316 quality.
The equipment consists of four cleaning arms, adjustable to the filtering screen two arms have anti wear nylon cleaning brushes and the other two in stainless steel.
The valid meshes for this equipments vary between 1.00 mm and 10.00 mm, the execution is in triangular or perforated profile depending on the mesh.
Driven by a motor reducer located in the top part of the equipment and out of reach of the flow to be treated, the TAC-01 ® screen filter the excess water and does not let the solids go trough, the spinning sense of the sweeping arms is contrary to the watch needles.
DESCRIPTION
Body: Monoblock execution, electrically welded and screwed, its construction is totally in stainless steel, a very robust equipment as well as simple, which simplifies significantly the maintenance works.
Cleaning arms: Four units, stainless steel fabrication Aisi 304 or 316 quality, there are two arms with nylon cleaning brushes and the other two in stainless steel, the brushes are adjustable to the filtering screen by means of regulation rods
Motor reducer: Normally endless crow, minimum protection IP-55, maximum IP-65, it actions by means of a transmission chain the cleaning arms, the exit speeds vary between 3.1 and 8.00 R.P.M.
