نام محصول:
شیر دیافراگم
نام انگلیسی:
Diaphragm valve
برند:
Athena Engineering S.r.l.
مشخصات:
Sliding Stem Valves Series
body material: Carbon steel /Stainless steel / Alloy steel /Special ( Monel /Inconel /Hastelly etc.) alloy steel
end connection: RF/RTJ/BW
operation: Diaphragm/ motor/pneumatic actuators
product overview： Athena valve body flow path is in the S type which provides a lower pressure loss, larger flow capacity, wider control range, higher control accuracy and offers a better performance in resistance to vibration.compact whole structure, high anti-pressue ability and can be applied to control different pressure and temperature fluid..
توضیحات:
Type
diaphragm
Operation
pneumatically-operated
Function
for control
Material$
steel, alloy, stainless steel, carbon steel
Other characteristics
high-performance, motor-driven, high-capacity, high-performance
DN
Min.: 15 mm(0.591 in)Max.: 900 mm(35.433 in)
Pressure
Min.: 16 bar(232.1 psi)Max.: 420 bar(6,091.6 psi)
