نام محصول:
سوپاپ
نام انگلیسی:
Pinch valve DV995
برند:
DIVATEC,SL
مشخصات:
Advantage
• High operating safety and long service life
• Requires little maintenance
• Simple union of the valve to the pipe by the proven bonding or welding process
Applications
• Construction of chemical facilities
• Water treatment
Use
• For the aeration of industrial plants
Function
• The valve ball / float obstructs the vessel by the force of the spring. The fluid or gases can not purge. If liquid is now removed from the container, a depression occurs in the container. When the forces -depression and strength of the dock-
The valve is neutralized and opened. The protective air / gas can enter the container.
Indication
• Conditioned by operation, only vertical mounting is possible
• The container can not be filled without additional deaeration.
• The opening pressure of the float or ball is approx. 0.05 bar.
• This value depends greatly on the temperature, the system pressure, the fluid and the degree of general fouling (crystallization), etc.
• Valves are not suitable for media that reduce the opening or closing of the ball / float due to deposition or adhesion.
توضیحات:
Type
pinch
Applications
for the chemical industry, for water systems
Associated function
vent
DN
Min.: 65 mm(2.559 in)Max.: 80 mm(3.15 in)
Pressure
10 bar(145 psi)
