نام محصول:
سوئیچ

نام انگلیسی:
Cam switch VN series

برند:
ELEKTRA TAILFINGEN Schaltgeräte GmbH & Co. KG

مشخصات:
VN series cam switches are manually operated cam switches suitable for an extremely wide range of uses and with practically unlimited switching possibilities. The cam switch’s base unit forms the contact chamber with the cam wheel for function control. Each chamber contains 2 double break contacts, with the moving contact bridges being controlled by the cam wheel via the contact slides. The opening of the contacts happens positively. VN switches can therefore be universally used and can be built as control switches, instrument switches, motor switches or main switches. The VN series includes a range of different sizes. The VN series cam switches have been developed, made and tested in accordance with the relevant national and international regulations. This line’s products fall into the area of applicability of EC Low Voltage Directive 2006/95/EC.

• On/Off switches
• Single-phase starter switches
• Toggle switches
• Reversing switches
• Star-delta switches
• Pole-changing switches for separated winding / Dahlander winding / 3 or 4 rotary speeds
• Control switches
• Ammeter toggle switches
• Voltmeter toggle switches
• Step switches, 1/2/3-pole

توضیحات:
Type
cam

Number of poles
4-pole

Protection level
IP54

Mounting
panel mount

Other characteristics
on/off, emergency power off

Primary current
25 A, 32 A

Voltage
400 V
