نام محصول:
سوئیچ تک قطبی
نام انگلیسی:
Single-pole switch SI-RFDL-HP8
برند:
TURCK
مشخصات:
Contactless safety sensor for cascading
Coding type: high
Reset: locked
Diagnostics: detailed ISD (in-series diagnostic) diagnostic system for a complete status image (not safety-relevant)
Operating status indicator (green/red)
Switching output indicator (yellow)
IP69K
SIL 3 (IEC 61508)
PL e (ISO 13849-1)
Required for operating SI-RF-A actuators
Country of origin – HU
Weight – 114 g
Technical Data
Function – RFID safety switch
Design – Rectangular
Range – 10…25 mm
Cascadable – Yes
With muting function – no
Start/Restart interlock – yes
Output function – 2 × OSSD, NO contacts, PNP
Communication protocol – ISD
Electrical connection – Cable with connector, M12 × 1
Cable length – 0.250 m
PL acc. to EN ISO 13849-1 – Level e
SIL acc. to IEC 61508 – 3
Category acc. to DIN EN 13849-1:2008 – 4
Coding level/tamper protection – High
Housing material – Plastic, Thermoplastic material
Ambient temperature – -25…+70 °C
توضیحات:
Number of poles
single-pole
Protection level
IEC, SIL 3, IP69K
Other characteristics
plastic, thermoplastic, RFID, safety, interlock, contactless, reset
Voltage
Min.: 19.2 VMax.: 30 V
Operating temperature
Min.: -20 °C(-4 °F)Max.: 70 °C(158 °F)
