نام محصول:
دمپر پالس دیافراگم
نام انگلیسی:
Diaphragm pulsation damper APT1 series
برند:
SAIP S.R.L.
مشخصات:
Technical data
Operating pressure:
APT 0.1>5 max 30 bar
Gas filling (nitrogen only): max. 90% of min. operating pressure
Admissible pressure ratio: max. ≤ 10/1
Operating temperature: -20 +140°C
Mounting: horizontal or vertical with gas valve upwards
Standard construction characteristics
Material of body:
APT 0.1>5 stainless steel AISI 316L
Diaphragm: PTFE
Gas connection valve: 5/8”UNF version 1
Painting: –
Test: on request
Also available for Pmax: 60/100/150/200/300/400 bar
توضیحات:
Heating technology
diaphragm
Applications
for pump
