نام محصول:
دریچه
نام انگلیسی:
Plug valve VDC
برند:
WAMGROUP S.p.A
مشخصات:
VDC Double Dump Valves are the ideal solution for controlled discharging of large particle size or particularly high temperature materials from silos, bins or hoppers in heavy-duty applications in virtually all industries.
VDC Double Dump Valves consist of a robust casing and two alternately activated flaps, one installed on top of the other.
VDC Double Dump Valves are the ideal solution for controlled discharging of particularly high temperature or abrasive, large particle size materials. They are most suitable for discharging dust from large de-dusting units and for heavy-duty applications in general, in virtually all industries. They are also used for processes that do not require continuous material flow.
VDC Double Dump Valves are designed to withstand high temperatures, for abrasive materials and those with irregular particle size in bulk solids handling processes in which constant material flow is important.
• Calculated for 600 activation cycles per hour at 50% loading
• Various materials available according to product handled
• Different types of control systems
توضیحات:
Type
plug
Operation
pneumatically-operated, electric
Function
for control
Body$
double
Applications
for the chemical industry, for bulk materials, for powders, for granulates, for silos, for the construction sector, for heavy-duty applications
Material$
stainless steel, carbon steel
Associated function
discharge
Other characteristics
high-temperature, rugged
Temperature
Min.: -10 °C(14 °F)Max.: 500 °C(932 °F)
Flow rate
Min.: 1 m³/h(35.31 ft³/h)Max.: 18 m³/h(635.66 ft³/h)
