نام محصول:
دریچه
نام انگلیسی:
Plug valve
برند:
Tengxuan
مشخصات:
Plug valve is a quick switch through valve, because the movement between the sealing surface with wiping effect, and in the full open can completely prevent the contact with the flow of media, so it usually can also be used with suspended particles medium.
Another important feature of the valve is that it is easy to adapt to the multi-channel structure, so that a valve can obtain two, three, or even four different flow channels.This simplifies piping design, reduces valve usage, and reduces the number of connections needed in equipment.
Main Feature
1. Straight through, integral body
2. Strong circulation capacity
3.Cartridge replaceable seat
4.No cavity passage, low fluid resistance
5.Two-way seal, adjustable device
6.Anti-static, fireproof structure
توضیحات:
Type
plug
Operation
lever, with handwheel
Body$
flange, straight
Other characteristics
anti-static, integral, flameproof
DN
Min.: 15 mm(0.591 in)Max.: 250 mm(9.843 in)
