نام محصول:
دریچه
نام انگلیسی:
Ball valve BV
برند:
Rotork
مشخصات:
High flow – Up to 19.0 Cv / 857.0 l/min Working pressure up to 10,000 psi / 690 bar NACE MR-01-75 internal wetted and body materials as standard Viton / RTFE Stem Sealing – maintenance free Low operating torque eliminating the need to mount on a back plate to counteract torque Non-rotating, anti-galling tip (selected models) Custom manifold solutions available Fire safe option available – Fire tested in accordance with AP1 607, API 6FA and ISO 10497 Further product configurations available Up to 1″” actuated solutions available
توضیحات:
Type
ball
Operation
lever
Body$
manifold
Applications
plate
Other characteristics
ISO, standard, actuated, high-flow, custom
Pressure
Min.: 0 psiMax.: 10,000 psi
Flow rate
Min.: 0 l/min(0 us gal/min)Max.: 857 l/min(226.4 us gal/min)
