نام محصول:
دریچه
نام انگلیسی:
Ball valve 0669 02 19
برند:
Parker Fluid System Connectors Division Europe
مشخصات:
Manually-operated valves offer a reliable and durable system for opening and closing the circuit when the system has to be switched frequently.
They provide a significant reduction in the time needed to work on pneumatic circuits.
Manually-operated valves offer a reliable and durable system for opening and closing the circuit when the system has to be switched frequently.
They provide a significant réduction in the time needed to work on pneumatic circuits.
Features/Benefrts:
-Manual Switch-Operated Valves
•Downstream control supply provided by simply moving the lever
•2 models available to provide the best solution for the system:
3/2: opening, closing, venting
2/2: opening, closing
•Compact and ergonomie (can be positioned through 360°)
•Push-in connections
-Valves with Sliding Sleeve
•Uni-directional use ensures the downstream circuit is vented
•Operated in the plane of the tube
•Lightweight due to the use of aluminium
•Idéal for complex installations in a restricted space
•Immediate identification of the venting system by the colour (red)
Product Types:
•3/2 Manual Switch-Operated Valve, Supply, Maie BSPP and Metric Thread
•3/2 Manual Switch-Operated Valve, Control, Maie BSPP Thread
•2/2 Manual Switch-Operated Valve, Maie BSPP Thread
•3/2 Sleeve Valve, Female BSPP and Metric Thread
Markets:
•Factory Automation
•Wearing Apparel
•Semiconductor
توضیحات:
Type
ball
Operation
manual
Function
for control
Media
for gas, for compressed air
Body$
threaded
Applications
for automobiles, for packaging
Material$
nickel-plated brass
Number of channels
3/2
DN
Min.: 4 mm(0.157 in)Max.: 10 mm(0.394 in)
Pressure
Min.: 0 bar(0 psi)Max.: 16 bar(232.1 psi)
Temperature
Min.: -10 °C(14 °F)Max.: 80 °C(176 °F)
