نام محصول:
دریچه
نام انگلیسی:
Butterfly valve TRIODIS 150
برند:
KSB
مشخصات:
Triple-offset butterfly valve, metal-seated (fire-safe), without gland packing, maintenance-free, with lever or manual gearbox, pneumatic, electric or hydraulic actuator. Body made of steel or stainless steel, full-lug body (T4), flanged body (T7) with flat or raised faces, body with butt weld ends (BWSE). Body types T4 and T7 are suitable for dead-end service. Connections to EN, ASME or JIS. Connections to ASME: Schedule 10S, 10, STD and XS to NPS for valves with butt weld ends (other connections on request). Fugitive emissions performance tested and certified to EN ISO 15848-1. Certified to German TA Luft Technical Guidelines on Air Quality Control. Fire-safe design tested and certified to EN ISO 10497 (BS 6755 – API 6FA). ATEX-compliant version in accordance with Directive 2014/34/EU. In compliance with NACE MR0175 / ISO 15156 and MR 0103.
Main Applications
Mining
Chemical industry
Petrochemical industry
Liquefied natural gas process
Pressure boosting
Shipbuilding
Pipelines and tank farms
Process engineering
Gas tanks
Industrial recirculation systems
Nuclear power stations
Air-conditioning systems
Fossil-fuelled power stations
Paper industry / pulp industry
Hot-water heating systems
Benefits
Tight shut-off
Perfect bi-directional shut-off: zero leakage to API 598, EN 12266, FCI 70-2, ISO 5208, ISO 28921-1, BS 6364
Positioning and locking of actuator flange
Actuator easy to remove and reinstall in the system
Ease of service
Seat can be replaced easily.
Innovative maintenance-free sealing system at the shaft passage
توضیحات:
Type
butterfly
Operation
lever, pneumatically-operated, electric, hydraulically-operated, manual
Media
petroleum, for gas
Body$
triple-offset
Applications
cryogenic, gearbox, for marine applications, actuator
Material$
steel, stainless steel
Other characteristics
with actuator, with butt weld ends, fire-safe
DN
Min.: 50 mm(1.969 in)Max.: 1,400 mm(55.118 in)
Pressure
25 bar(362.6 psi)
Temperature
Min.: -250 °C(-418 °F)Max.: 260 °C(500 °F)
